CA6140车床拨叉夹具设计

范文编号:JX718  范文字数:8545.页数:28   附CAD图

摘  要
 本设计是CA6140拨叉的加工工艺规程及某道工序的专用夹具设计。CA6140拨叉的主要加工表面是三面两孔。一般来说，平面的加工精度要比孔的加工精度更容易保证。因此，本设计遵循先面后孔的原则，并将孔与平面的加工明确划分成粗加工和精加工阶段以保证孔的加工精度。先将第一个待加工表面零件的左端面加工出来，再以底面为粗基准加工零件顶面，并以零件的顶面作为精基准以完成以后的孔的加工。所以选择以零件左端面作为粗基准，以的孔作为精基准，整个加工过程选用组合机床，在夹具方面选用专用夹具。考虑到本零件结构的特殊性，以及所需的夹紧力较小等原因，本零件的夹紧方式采用螺旋夹紧机构。

关键词：夹具，加工工艺，工艺规程，定位

CA6140 lathe processing technology fork and Fixture Design
Abstract
 CA6140 fork of the design is a point of order processing technology and procedures in a dedicated fixture design. CA6140 fork of the main surface is two holes on three sides. Generally speaking, the plane of the machining accuracy of the machining accuracy than the hole more easily guarantee. Therefore, the first surface of the design followed the principles of post-holes, and holes with the two-dimensional processing clearly divided into roughing and finishing stages of processing to ensure the accuracy of the hole. First processing the surface of the first parts to be left out of face processing, and then to the bottom parts for rough machining the top face of the base and top parts as to complete the baseline precision of the hole after the processing.And therefore he chose to spare parts as a left-side rough, with a precision of the hole as a benchmark,the whole combination of machine tool selection process, in selected aspects of exclusive jig fixture. Taking into account the specificity of the structure of the parts, as well as a smaller clamping force required for other reasons, the parts of the clamping means clamping screw body to adopt.

Keywords: Fixture ,Components processing ,technology Process, Positioning
