65LB15-50型螺杆泵设计

范文编号:JX760  范文字数:8777.页数:26   附CAD图

摘     要
 本范文提出泵属于流体机械，是一种将原动力所做的功转化为被输送流体的压力势能和动能的流体机械。螺杆泵是利用螺杆的回转来吸排液体的。螺杆与衬筒内壁紧密配合，螺杆在泵的吸入口和排出口之间就会被分隔成一个密封空间。随着螺杆的转动和啮合，密封空间在泵的吸入端不断形成，将吸入室中的液体封入其中，并自吸入室沿螺杆轴向连续地推移至排出端，将封闭在空间中的液体不断排出，犹如一螺母在螺纹回转时被不断向前推进的情形那样，这就是螺杆泵的基本工作原理。椐目前的实际应用及有关资料显示，螺杆泵的应用范围很广，它的特点是流量平稳、压力脉动小、有很强的自吸能力、噪声低、效率高、寿命长、体积小、工作可靠。突出的优点是输送介质时不形成涡流、可输送粘度范围宽广的各种介质，既可以输送各种粘度的润滑性或腐蚀性介质，也可以输送各种粘度的非牛顿液体，还可以气液混输、固液混输。它广泛应用于海上平台工程、石油化工、航运、电力、机械液压系统、建材、水利、船舶、码头、港口、油库、食品、造纸、制糖、军工和污水处理等工业部门。

关键词：螺杆泵 设计 工程制图 水力计算

65LB15-50-type screw pump design

Abstract
 This paper presents mechanical pump is fluid, is a kind of power will be the driving force behind efforts to be transmission fluid into the pressure of potential energy and kinetic energy of fluid machinery. Screw is turning to the use of screw liquid smoke emission. Screw and tube wall lining, close co-operation of the screw in the pump intake and outlet will be divided into between a sealed space. With the rotating screw and mating, sealing the space in the pump suction side evolving to inhaled enclosed room in which the liquid, and from inhalation of room along the screw axis to move from row to push the client, will be closed in the space of continuous discharge of liquid, like a nut in the thread when he was constantly turning the situation to move forward, this is the basic working principle of the screw pump. Show the practical application of current and relevant information, screw covers a wide range of applications, it is characterized by a smooth flow, the pressure pulsation of small, have a strong self-absorption capacity, low noise, high efficiency, long life, small size, reliable work. Highlight the advantage of conveying the formation of eddy current media is not to transport a wide range of viscosity of various media, we can transfer all kinds of lubricating viscosity or corrosive media, can also transport a variety of non-Newtonian fluid viscosity, but also gas-liquid mixture can lose, lose the solid-liquid mixing. It is widely used in offshore platform engineering, petrochemicals, shipping, electrical, mechanical hydraulic systems, building materials, water, ships, terminals, ports, oil depots, food, paper, sugar, military and industrial sectors, such as sewage treatment.
Keywords：Screw pump  design  Engineering Drawing  Hydraulic calculation

目  录
中文摘要 II
英文摘要 III
目    录 Iv
第一章 绪论 1
1.1概论 1
1.2螺杆泵发展概况 1
1.3设计基本方案 2
第二章.螺杆泵的结构设计 3
 2.1螺杆泵的主体结构综述 3
 2.2螺杆泵的主体结构分析 3
3.1设计计算综述 6
3.2主要参数设计计算及技术指标 6
3.3水力设计计算 7
3.4电机的选用 8
3.4.1Y系列小型三相异步电动机 9
3.4.2Y系列小型三相异步电动机的安装及外形尺寸 10
3.5联轴器的选择 11
3.5.1选择联轴器的类型 11
3.5.2确定联轴器的型号 12
 3.5.2.1校核最大转速 12
3.6 键的选择计算 14
3.7轴承的选用 15
3.7.1单向推力球轴承 15
3.8螺杆处万向节的选取 16
3.9轴与轴承部件尺寸计算与校核 17
3.9.1轴的强度计算 17
3.9.2轴的结构设计 18
结   论 20
主要参考文献 21
致  谢 22
