变速器操纵系统设计

范文编号:JX784  范文字数:17980.页数:55   附CAD图

摘    要
 变速器操纵系统主要由换档手柄、套管、防尘罩、操纵器总成、选档软轴、换档软轴、软轴支架、U型夹总成、选档摇臂、换档助力器组成，操纵器总成上的换档杆穿过驾驶室地板上的长方孔，操纵器总成支架固定在地板上；换档手柄、套管、防尘罩均套在操纵器忠诚的换档杆上；防尘罩与驾驶室地板密封连接成一体；选档软轴、换档软轴连接操纵器总成，并通过U型夹总成固定在换档软轴支架和选档软轴支架上，并分别固定在离合器壳和变速器上盖上；选档软轴与选档摇臂连接，选档摇臂连接在变速器选档轴上，换档软轴与变速器换档助力器连接。具有结构合理、操作简单、安装方便、美观大方、性能可靠等优点。现在常用的变速器操纵杆大致可以分两种：直接操纵式和远距离操纵式，前者在变速器布置在驾驶员座位附近，变速杆由驾驶室底板伸出，驾驶员可直接操纵。这种操纵机构一般由变速杆、拨块、拨叉、拨叉轴以及安全装置等组成，多集装于变速器上盖或侧盖内。后者在当驾驶员座位离变速器较远或变速杆布置在转向盘下方(某些轿车)的转向管柱上时，通常在变速杆与换档拨叉之间增加若干个传动件，组成远距离操纵机构。变速器远距离外操纵机构 1-变速杆 2-纵向拉线 3-横向拉线
 本范文结合文档实习公司项目“吉利FC-1变速器支架设计”，首先分析了国内外当前普遍采用的汽车变速器操纵系统类型、结构和特点；给出本实习期间设计的国内一款手动汽车变速器操纵系统，并给出具体的总成及零部件设计结果。在此基础上对汽车总成公司要求的相关重要零部件进行了结构强度和疲劳强度的校核计算，并在Pro-E三维绘图软件上进行了造型构建。通过文档实习的锻炼和本范文的撰写，基本掌握了汽车变速器操纵系统的结构设计，具备了一定的设计能力。
关键词：变速器操纵系统；系统设计；强度校核；Pro-E

Abstract
 Transmission system is mainly controlled by the shift lever, casing, dust cover, manipulation ASSY election profile shaft, transmission shaft, flexible shaft bracket, U-type assembly folder, choose File rocker, transmission booster composition, the shift control rod assembly through the cab of the rectangular hole on the floor, pulling the stent ASSY fixed on the floor; shift lever, casing, dust cover both sets of loyalty in the manipulator transmission poles; Dustproof sealed connection with the cab floor into one; election profile flexible shaft, flexible shaft connected shift control assembly, and through the fixed U-folder in the shift shaft assembly and the election stent soft file stent axis, and were fixed on the clutch and gearbox shell stamp; selected file file rocker shaft connected with the election, the election connection file rocker shaft in the transmission file selection, and transmission gear shift shaft connection booster . Reasonable structure, simple operation, easy installation, beautiful person, the advantages of reliable performance.   Joystick is now commonly used in transmission can be divided roughly in two forms: direct manipulation and remote manipulation of type, the former transmission arranged in the vicinity of the driver seat, floor gear lever protruding from the driver's cab, the driver can be directly manipulated. This manipulation generally by the gear lever, call block, fork, fork shaft, as well as the composition of safety devices, etc., multi-set or installed on the transmission side cover in shelters. The latter in the seat when the driver away from the transmission gear lever or steering wheel arranged in the bottom (some cars) on the steering column, they will usually stick shift fork and shift transmission between the increase in number of cases, the composition of remote control agencies. Institutions outside the remote control transmission 1 - shift 2 - vertical lines 3 - horizontal lines
 In this paper, the company combined with graduate training project "Geely FC-1 transmission stent design", the first analysis of the current commonly used at home and abroad of the type of vehicle transmission control system, structure and characteristics; given the design of the internship period, a domestic auto transmission manual control system, and gives specific design assembly and parts. On this basis the requirements of the automotive assembly companies important components related to the structural strength and fatigue strength calculation of the check, and Pro-E three-dimensional mapping software to build a model. Graduate training through the internship and the writing of this paper, the basic grasp of the motor vehicle transmission control system of structural design, with a certain degree of design capability.
Keywords: automotive transmission control system   System Design   Strength Check    Pro/E

目  录
中文摘要 i
英文摘要 ii
目录 iii
第一章     绪论 1-8
 1.1  汽车变速器及其操纵系统 1
 1.2  自动变速器的基本组成 5
 1.3  研究背景 7
 1.4  研究动机与目的 7
 1.5  范文內容概述 8
第二章     汽车变速器操纵系统总体设计 9-19
 2.1   汽车手动变速器操纵系统原理分析 9
 2.2   吉利远景FC-1变速器操纵系统零件组成及其设计 10
 2.3   本章小结 19
第三章     操纵系统关键零部件强度设计 20-26
 3.1   复位弹簧设计 20
 3.2   操纵杆的强度校核 22
 3.3   支架的疲劳强度校核及其CAE的仿真模拟 24
 3.4   本章小结 26
第四章     基于ProE的汽车变速器操纵系统设计和分析 27-48
 4.1   ProE软件简述 27
 4.2   基于PROE汽车变速器操纵系统及各零件的开发 30
 4.3   装配效果图和装配说明 46
 4.3   本章小结 48
第五章     小结 48-48
参考文献 50
致谢 51
