张臂式汽车电动窗帘的结构设计

范文编号:JX814  范文字数:15211.页数:40   附CAD图

摘     要

 做为生活中必不可少的代步工具—汽车，已经越来越成为大众的消费品，各种不同牌子型号的车都装有丰富的操作系统，很多操作都能达到电动化的程度，就连汽车窗帘也可以电动控制。就现在而言，电动窗帘虽然在国内并没有普及，但是凭借它自身的优点，随着科技的提高，人们对电动窗帘的更多了解，电动窗帘会更加深入的走进人们的生活。
 我们本着节约资源，优化操作，快捷环保的原则设计一款价廉物美的汽车电动窗帘，根据其运行原理暂名为张臂式汽车电动窗帘，该设备能完全代替市面上其他的一些这样设备，真正意义上做到保护隐私，单向透光，隔热阻紫外线等强大功能。
 我们设计的张臂式汽车电动窗帘是用用电机驱动，减速器控制速度，通过拉索和摆臂进行窗帘的升降，结构简单，拆装方便，价廉物美，耐用实惠。

关键词： 汽车 电动窗帘 张臂式

 Cantilever type automobile automatic window blind structure design

 Abstract

 Compose for the implement automobile living to be hit by essential riding instead of walk, Tend to masses's consumer goods already especially, various different brand type capital of vehicle pretends to have rich OS, many operation all can reach electric-rization degree, controls with regard to even automobile curtain being able to be electric. As far as now be concerned, the electric curtain popularizes, does not but relies on its self's merit, with science and technology rise though in in the homeland , people directs on more electric curtain .know about, electric curtain life walking into people that can go deep into especially.
 We are handled according to saving resource, optimization, rapid environmental protection principle designs electric one automobile curtain good and cheap , run the electric principle curtain for the moment called dyadic automobile of arm spread according to the person , is equipment's turn to be able to replace city surface completely other some such equipment , really achieve on significance protecting private matters one wants to hide , one-way transmitting , heat insulation hinder an ultraviolet ray from waiting for the function big and powerful.
 The electric dyadic automobile of arm spread curtain that we design is to use electric motor to drive , reduction gear controls speed, promotion and demotion , structure passing a dragline and laying bare an arm carrying out a curtain dismount convenient , good and cheap , durable tangible benefit simplely.

Keywords:   car    Electric curtain    Arm spread is dyadic
