铸造车间负压除尘系统的设计

范文编号:JX1568  范文字数:18958.页数:41 附任务书，开题报告，外文翻译,CAD图

 铸造车间负压除尘系统的设计

摘要：
 粉尘是人类健康的大敌，因为它带着许多细菌病毒和虫卵到处飞扬，传播疾病。. 工业粉尘、纤尘能使工人患上各种难以治愈的职业病，过多的灰尘还会造成环境污染，影响人们的正常生活和工作，诱发人类呼吸道疾病等等。除尘器是在车间必不可少。
 利用旋转的含尘气体所产生的离心力，将粉尘从空气中分离出来的一种干式净化设备，成为旋风除尘器。旋风除尘器应用最为广泛，，其特点是结构简单，除尘效率较高，操作简单，价格低廉。旋风除尘器对于大于10μm的较粗粉尘，净化效率很高。但对于5~10μm以下的细颗粒粉尘净化效率较低，所以旋风除尘器多用于粗颗粒粉尘的净化，或多用于多级净化的初步处理。适用于铸造车间除尘。
 负压除尘系统中，除尘器设置在通风机之前。
 其特点： ①由于除尘器设置在通风机之前，流过通风机的气体已经经过除尘，含尘量低。通风机受磨损大大减低，运行寿命长，处理初浓度高的含尘气体时，一般采用负压除尘系统。②除尘器和管道处于通风机的负压阶段，容易吸入空气，产生漏风。负压除尘系统的漏风率为5%~10%，加大了通风机的风量，增加了电耗。③在负压除尘系统设计中应采用措施尽可能的减少除尘器和管道的漏风，以保证除尘器的良好运行。

关键词： 铸造     旋风除尘器    负压除尘

 Dust vacuum system design
Abstract:
 Dust ,which carries lots of bacterial  virus  and ovum  flying forwarding in the air ,has become a  formidable enemy of human being ,endangering the mankind’s health , Industrial dust and fine dust cause various kinds of incurable occupational disease among workers. Also, excessive dust leads to environmental pollution, having a influence on the people’s daily lives and work, causing respiratory disease,etc. All these make the Dust collector indispensible   in the workshop.
 By using the cyclone dust rotating centrifugal force generated by gas, the dust is separated from the flow of a dry gas - solid separation device, which forms the Cyclone Dust Collector. The Cyclone Dust Collector is widely used, which featured in it’s simple structure, effectiveness in dust removal, simple operation, and low cost. Cyclone Dust Collector is efficient for the capture, separation of more than 5 ~ 10μm dust. But as to the dust under 5-10μm ,it performs less effectively. Therefore, the Cyclone Dust Collector is mostly used in the casting workshop, purifying the coarse particle dust or becomes the primary treatment of multistage purification.
   In the negative pressure dust pelletizing system ,removal equipment was set in front of the ventilator .it’s characteristics are as follows : 1.Because the removal equipment was set in front of the ventilator ,the gas passing through the ventilator has been removed ,therefore, the dustiness index is low 2.The dust collector and the pipeline situated in the negative pressure section ,which is easy to  snifting the air ,leads to air leak .the air leak ratio of dust vacuum system is 5% to 10% ,increasing the air quantity of ventilator ,which leads to the electricity cost. 3. should be reduced in the dust collector and pipeline as much as possible In designing the dust vacuum system.
 Key words: Casting, Cyclone Dust Collector, vacuum dust removal 目   录
