2K-H型行星减速箱设计

范文编号:JX1571  范文字数:11440.页数:36 附任务书，开题报告，外文翻译,CAD图

2K-H行星减速箱设计
摘要：在给定传动比、扭矩、模数及行星轮个数的条件下进行了行星减速器的总体方案设计、常规设计计算、输出轴的工艺流程设计及绘制总装图和部分零件图。
 行星减速器的总体方案设计选用太阳轮浮动的均载机构，太阳轮通过单齿联轴器与高速轴联接实现浮动，这种浮动方法浮动灵敏，结构简单，易于制造，便于安装。太阳轮与齿轮联轴器的外齿半联轴套做成一体，内齿轮设计成内齿圈的结构，行星架选用刚性较好的双侧板整体式结构，与输出轴法兰式联接，行星架与输出轴通过两个对称布置得定位销保证同轴度。齿轮联轴器选用鼓形齿齿轮联轴器，鼓形齿齿轮联轴器允许两轴线有较大角位移，相对承载能力较强，并且易于安装调整。减速器齿轮采用油池润滑，轴承采用飞溅润滑。
 根据总体设计方案和常规设计计算绘制总装配图以及太阳轮、行星架、输入轴、输出轴的零件图。
 输入轴的工艺流程设计对输入轴进行工艺分析，绘制零件图；确定毛坯的制造形式；制定零件的机械加工工艺路线并填写工艺过程卡和工序卡。

关键词：2K-H  行星齿轮  减速箱

2K-H planetary gear box design
Abstract：In a given gear ratio, torque, modulus, and the number of planets round under the conditions of the planetary reducer for the overall program design, conventional design, the output shaft of the process design and draw parts assembly diagram and Fig.
 Planetary reducer selection of the overall design of the sun round the floating bodies are set, the sun wheel gear coupling with a single high-speed shaft connected to the realization of floating, the floating floating method is sensitive, simple structure, easy to manufacture, easy to install. Round the sun gear coupling with the second half of the outer sleeve teeth into one, with gear designed with the structure of ring gear, planetary rigid frame a better selection of both the overall board structure, with the output shaft flange-type connection, planetary output shaft through the frame with two pins in a symmetrical arrangement to ensure coaxiality. Selection of drum gear coupling tooth gear coupling, gear coupling crown gear axis to allow the two larger angular displacement, load-bearing capacity is relatively strong, and easy to install and adjust. Used oil tank gear reducer lubrication, bearing lubrication using splash.
 According to the overall design of conventional design and calculation programs and the general assembly drawing, as well as round the sun, planetary plane, input shaft, output shaft of the parts diagram.
 Input shaft of the process design of the input shaft to process analysis, mapping parts diagram; to determine the manufacture of blank forms; the development of parts of the machining process and complete the process route and process Card card.

Key words: 2K-H   planetary gear   reducer box

 目     录
1  前言  1
 1.1选题的依据及意义  1
    1.2国内外研究概况及发展趋势  1
2  常规设计计算 3
 2.1已知条件 3
 2.2设计计算 3
 2.2.1 选取行星轮传动的传动类型和传动简图 3
 2.2.2 行星轮传动的配齿计算 3
 2.2.3初步计算齿轮的主要参数 4
 2.2.4装配条件的验算 5
 2.2.5传动效率的计算 6
 2.2.6减速器的润滑和密封 10
 2.2.7 齿轮强度验算 10
 2.2.7.1校核其齿面接触强度 10
 2.2.7.2校核其齿跟弯曲强度 13
3  结构设计计算 15
 3.1行星架的结构设计与计算 15
 3.1.1行星架的结构设计 15
 3.1.2行星架结构计算 15
 3.2齿轮联轴器的结构设计与计算 16
 3.3轴的结构设计与计算 17
 3.3.1输入轴的结构设计与计算 17
 3.3.2输出轴的设计计算 19
 3.4铸造箱体的结构设计计算 20
4  输入轴的工艺设计 22
 4.1零件的分析 22
 4.1.1零件的图样分析 22
 4.1.2零件的工艺分析 22
 4.2工艺规程设计 23
 4.2.1确定毛坯的制造形式 23
 4.2.2基面的选择 23
 4.3制定工艺路线 23
 4.3.1工艺路线方案一 23
 4.3.2工艺路线方案二 24
 4.3.3工艺路线方案三 25
 4.4机械加工余量、工序尺寸及毛坯尺寸的确定 25
 4.4.1机械加工余量的确定 25
 4.4.2毛坯尺寸确定 26
 4.5确定切削用量及基本工时 26
总结与评价  34
 参考文献 35
 致谢 36
