气流雾化喷枪的设计

范文编号:JX1628  范文字数:15981.页数:30 附任务书，开题报告，外文翻译,CAD图

气流雾化喷枪的设计
摘要：高压喷涂是一种利用压缩空气为动力，不直接用压缩空气对涂料进行雾化，它用增压泵将涂料增压至10Mpa-25Mpa，高压涂料通过喷嘴的小喷孔高速喷出雾化分散成极细的雾滴，同时将雾化涂料微粒推至被涂工件表面。
    利用高速气流而令喷枪局部真空，因而产生吸力把油漆从壶中吸到喷咀加以雾化喷出，主要作大面积喷涂，好处是油漆的雾化较佳，可以达到漆膜的厚度及光泽度要求。压力桶为圆柱形压力容器，一般用不锈钢或碳钢制作，桶盖上设置调压阀、压力表及安全阀等附件，调节输入压缩空气的压力可达到输出涂料的压力。压力桶有的还配置气动搅拌器，常用压力桶的容量为10L、20L、40L等。压力桶结构简单，维护方便，涂料输出压力较稳定，不足之处是清洗换色不便。
    空气喷枪的空气帽（空气喷嘴）、喷嘴（涂料喷嘴）和顶针，习惯称为空气喷枪的三件套是决定空气喷涂的涂装质量关键部分。气动双隔膜泵，是利用压缩空气作动力，通过换向机构使空气压力作用在横隔膜的内侧，而横隔膜的外侧与泵体共同组成一个容积可以变化的涂料腔。 当左面涂料腔容积从小变大产生局部真空，下面一个单向阀开启，上面一个单向阀关闭，涂料桶中的涂料在大气压力下进入左面涂料腔，而右面涂料腔容积由大变小，下面一个单向阀关闭，涂料产生压力，顶开上面一个单向阀排出泵体。双隔膜泵的两侧有两个涂料腔，当一个容积由小变大，则另一个容积由大变小，周而复始，往返进行。所以双隔膜泵的每次往复都有两次涂料吸入和排出，使泵的输出效率提高，而且输出相对比较平稳。由于压缩空气的输入压力和涂料的输出压力的比率为1:1,故调节压缩空气的输入压力的大小可改变涂料的输出压力。
   高压喷涂可以使用高粘度涂料，大面积喷涂速率达4m2/min-7m2/min，生产效率高。喷涂对涂料无压缩空气混入，漆雾反弹飞散的现象较空气喷涂少，降低了涂料消耗，改善了环境污染。 高压无气喷涂的出漆量较大且漆雾细度不够柔软，涂层厚度不易控制。精装饰涂膜喷涂不及空气喷涂细致。 一般适用于单品种粘度较高的涂料和形状简单、表面积较大的工件批量生产。广泛用于造船、集装箱、钢结构件、建筑内外墙、大型管道等行业。
关键词：压送式喷枪 压缩空气 空气喷枪 气动高压喷涂 气动柱塞泵
        顶针  空气帽

 Air spray gun design
Abstract:   High pressure airless spray gun is a kind of to make use of the compredded air as power, not and directly use the compredded air carries on atomization to the coating, it presses pump to press the coating super - to the 10 Mpas Mpas-25ses with the super -, the high pressure coating passes nozzle of small spray gun hole the high speed spew out the atomization scatter into the most slender fog drop, at the same time atomization coating the corpuscle push into drive Tu Gong Jian's surface.
   Make use of top speed air current but make air gun partial uvauum, as a result generate the vacuum force absorbs to spray Ju to take into atomization jet from the pot the paint and mainly make big area spray gun, the advantage is that the atomization of paint is better, can hit the thickness and water request of painting the film.The press barrel is the cylinder shape press container, generally use stainless clad steel or straight carbon steel creation, the barrel covers setup to adjust to press accesserieses such as valve, pressures gauge and safety valves etc., and the conditioning inputs the press of compredded air to hit the press of outputting the coating.Press barrel have of still install agitator air, the capacity of the wirking pressure barrel is for the 10 Ls, 20 Ls, and 40 L...etc..Press barrel the structure is simple, the maintenance is convenient, the coating outputs press more stable, scarcity of section is cleaning change a color inconvenience.
   Air cap(air noozle), nozzle(coating nozzle) and vertex needle that compresses an air gun, habitually be termed three sets of compressing the air gun is decide air to spray Tu Zhuang mass key fraction.The gas moves a pair of septums pumps, is to make use of compredded air to make power, pass to change to make to get empty a barometric pressure action in the diaphragmatic seamy side toward the mrvhsnidm, while diaphragmatic outside side and pump body constitute a coating chamber that volume can change together.When the left side coating chamber volume became big to generate partial uvauum since the childhood, underneath an one-way valve opened, up an one-way valve locks, the coating in the coating barrel entered a left side coating chamber under the atmospheric pressure, but right surface coating chamber volume from greatly diminished, underneath an one-way valve lock, the coating generated press, the vertex opened over - an one-way valve discharged to pump a body.Two sides of double septum pump contain two coating chambers and be a volume from small become big, then another volume from greatly diminish, go round and begin again, go back and forth progress.So double the septum pump of every time back and forth have two coating suction and discharge and make the output efficiency of pump exaltation, and output contra more steady.Because the ratio of the input press of the compredded air and the output press of the coating is 1:1, the output press of the dimension convertibility coating of the input press of past conditioning compredded air
   High pressure airless spray gun can use higher - viscosity coating, big area spray gun speed reach to the 4 ms 2/ms min-7s 2/min, the production efficiency is high.Spray has no compredded air vs the coating interfusion, paint fog rebound to fly a loose phenomemon compare air spray gun Tu Shao, lowered coating dissipation, improved public nuisances. High pressure airless spray gun's lacquer measures a little bit greatly and paints fog thin degree not enough soft, Tu Ceng's thickness doesn't easily control.The Jing decorates a spray gun of Tu Mo to cannot compare with air spray gun meticulous. Generally compliant unipole species viscosity the higher coating is as simple as shape, the surface accumulate a bigger work piece quantity production.Extensively used for a shipbuilding and gather vanning, the steel structure crafts, such as piece, outside wall inside the building and large piping...etc..
Keywords:  Press a send type air gun  Compredded air  Compress an air gun  The gas moves high pressure airless spray gun  The gas moves plunger pump  Vertex needle  Compress a cap

 目录
1  前言……………………………………………………（8）
2  喷枪简介………………………………………………（9）
  2.1 喷枪的类型……………………………………………………（9）
3  雾化原理………………………………………………（9）
4  气流雾化喷枪的通堵结构方案…………………… （9）
5  喷枪的主要零件………………………………………（12）
  5.1 现将喷头的三个主要件特性介绍 ……………………………（13）
  5.2 喷涂输漆可分为压力桶、气动双隔膜泵……………………（14）
  5.3 喷枪结构技术改造………………………………………………（14）
6  按喷枪工作原理分三类………………………………（24）
  6.1 吸上式、重力式和压送式三种吸上式喷枪………………………（24）
  6.2 喷枪操作及其要点…………………………………………………（25）
7  喷枪的维护与故障处理………………………………（26）
8  气流雾化喷枪的设计与功能………………………（28）
  8.1 特点及应用……………………………………………………（28）
9  供料方式喷枪的雾化技术及其发展趋势……………（29）
结论…………………………………………………………（31）
参考资料……………………………………………………（32）
致谢…………………………………………………………（32）

 《气流雾化喷枪的设计》WORD格式全文下载链接
