接触片冲压模设计

范文编号:JX1678  范文字数:9861.页数:33 附任务书，开题报告，外文翻译，答辩PPT,CAD图，UG三维图

 接触片的冲压模设计
 【摘要】本文阐述了冲压模具的概况、特点、以及在各方面的应用情况,对接触片的工艺性、经济性分析、排样图的设计、模具的方案确定、模具结构设计、模具装配图与零件图的绘制。
 接触片包括冲孔和落料两个基本工序，由于零件是大批量生产，因采用级进冲裁，以提高生产效率，方便操作。该零件材料厚度较薄，尺寸小，近似 T 形，采用45 度的斜对排样。为了保证零件的精度，模具采用导料板导向，侧刃定距的定位方式。零件厚度较薄，采用弹性卸料方式和导向相对平稳的对角导柱模架。
 【关键词】 级进模 ;排样; 冲孔; 落料

  Contact strip ramming mold design
 [Abstract]: This article elaborated the ramming mold survey, the characteristic, as well as in various aspects application situation, to contact strip technology capability, efficient analysis, platoon specimen map design, mold plan determination, mold structural design, mold assembly drawing and detail drawing plan.
  The contact strip and falls the material two essential working procedures including the punch holes, because the components are the mass production, because uses the level to enter the blanking, enhances the production efficiency, facilitates the operation. This components material thickness is thin, the size is small, the approximate T shape, uses 45 degree diagonally opposite row of type. In order to guarantee the components the precision, the mold uses leads the yard lumber guidance, leans locate mode which the edge is apart from surely. Components thickness is thin, selects the elastic ex-denning method and the guidance relatively steady opposite angle guide pillar pould frame.
  [Key words]: The level enters the mold; Row of type; Punch holes; Falls the material

目录
文档设计（范文）任务书  Ⅰ
开题报告       Ⅱ
中文摘要     Ⅵ
外文摘要    Ⅶ
1  序 言 1
 1.1 冲压冲压的概述、特点及应用 1
 1.2 接触片冲压模具的课题研究意义 2
 1.3 接触片冲压模具的课题研究主要内容 2
2  工件的工艺性分析 3
 2.1 冲压件的工艺性分析 3
 2.2 冲压加工的经济性分析 4
 2.3 确定工艺方案 4
3  主要工艺参数计算 5
 3.1 排样图分析 5
 3.2 计算冲压力 10
 3.3 计算压力中心 12
 3.4 选择冲压设备 12
 3.5 凸、凹计算及间隙的刃口尺寸的确定 13
4  模具主要零件及结构设计 17
 4.1 卸料板的设计计算 17
 4.2 定位导向机构的设计 19
 4.3 凸、凹模的尺寸设计 19
 4.4 固定板的设计计算 20
 4.5 模柄和模座的设计 21
 4.6 模具的闭合高度计算 23
 4.7 压力机的验证计算 23
5  绘制零件图、装配图及UG零件图 24
 5.1 绘制装配图 24
 5.2 绘制UG零件图 28
6  总结 29
参考文献 30
致谢        31
