包装机设计

范文编号:JX1494  范文字数:17052.页数:34 附开题报告，实习报告，外文翻译，CAD图，PPT

摘要
 目前，我国的食品包装企业大部分规模偏小，“小而全”是其主要特征之一，同时存在着不顾行业发展要求，重复生产那些成本低、工艺水平比较落后、易于制造的机械产品，行业内目前大约有1/4的企业存在低水平重复生产现象。这是对资源的极大浪费，造成包装机械市场的混乱，阻碍行业的发展。
随着科学技术的不断发展，各种食品、水产加工品的出现，对食品包装技术和设备都提出了新的要求。目前，食品包装机械竞争日趋激烈，未来的食品包装机械将配合产业自动化，促进包装设备总体水平提高，发展多功能、高效率、低消耗的食品包装设备。
 真空包装技术起源于20世纪40年代。自1950年聚酯、聚乙烯塑料薄膜成功地应用于商品包装以来，真空包装机便得到迅速的发展，其技术发展趋势主要体现在高生产率、自动化、单机多功能、组成生产线、采用相关新技术这5个方面。

Abstract
 Currently, our country's food packaging enterprise most smaller scale, "complete" is one of the main features, exist disregard industry development requirements, repeat production cost is low, the craft level who is relatively backward, easy to manufacture mechanical products, industry within roughly a quarter of enterprise existence low-level repeating production phenomenon. This is a tremendous waste of resources, to cause confusion, packaging machinery market hampering the development of industry.
 Along with the science and technology unceasing development, various food, the emergence of aquatic products, food packaging technology and equipment are put forward new requirements. At present, food packaging machinery increasingly fierce competition, the future food packaging machinery industrial automation, promote will cooperate with the overall level of packaging equipment rise, development multi-function, high efficiency and low consumption of food packaging equipment.
 Vacuum packaging technology originated in the 1940s. Since 1950 polyester, polyethylene plastic film applied successfully in the commodity packaging, vacuum packaging machine since then obtains the rapid development, the technology development trend are mainly embodied in the high productivity, automation, LAN multi-function, composition line, adopt new technology related to these five respects.


目录
1. 包装机简介 4
1.1包装机 4
1.2流水线式整体生产包装 4
1.3产品外围包装设备 4
1.4包装机的分类： 4
1.5包装机故障诊断及解决方法 6
1.6真空包装机介绍 6
1.7自动包装机的优势 8
1.8自动套袋包装机介绍 9
2. 我国包装机械行业的发展与前景 10
2.1我国食品包装机械发展前景预测 11
2.2  21世纪真空包装机发展趋势 12
2.3封箱机分类 13
2.4装盒、装箱包装线 14
2.5液体灌装机及其流水线 14
2.6小型真空包装机 15
2.7粉剂颗粒液体包装机 15
2.8各种包装机的分类与适用范围 16
3.方案的选择 19
3.1  功能要求 20
3.2结构方案设计 20
4.包装机机械运动部分设计 21
4.1总体方案的确定 22
4.2电动机的选择 23
4.3主轴传动设计计算 23
4.4齿轮的校核 25
5. 传动系统的设计计算 30
5.1主轴箱总体尺寸 30
5.2薄膜辊总体尺寸 31
6. 文档设计总结 32
致谢 33
参考文献 34

 《包装机设计》WORD格式全文下载链接
