把接头冲二孔模设计

范文编号:JX1673  范文字数:11700.页数:24 附任务书，开题报告，外文翻译，答辩PPT,CAD图

把接头冲二孔模设计
 【摘要】模具是在工业生产中，用各种压力机和装在压力机上的专用工具，通过压力把金属或非金属材料制出所需形状的零件或制品，这种专用工具统称为模具。我们日常生产、生活中所使用到的各种工具和产品，大到机床的底座、机身外壳，小到一个螺丝、纽扣以及各种家用电器的外壳，无不与模具有着密切的关系。模具的形状决定着这些产品的外形，模具的加工质量与精度也就决定着这些产品的质量。因为各种产品的材质、外观、规格及用途的不同，模具分为了铸造模、锻造模、压铸模、冲压模等非塑胶模具，以及塑胶模具。
 本次设计的把接头就属于冲压模，在冲压生产中，常常将几个单工序冲压过程集中在一副模具中完成，这种在压力机的一次工作行程中，在一副模具的同一工位同时完成两种或两种以上基本工序的模具就称为复合模具。
 【关键词】把接头  冲压模

The handlebar punch two hole die design
 [Abstract] Dies in industrial production, with a variety of presses and installed a special tool in the press, through pressure or non-metallic materials, the metal shape of the required parts or products, this special tool referred to as mold. Our everyday life and production used a variety of tools and products to the large to the machine base, the body shell, a small screws, buttons and various household appliances in the shell, all have a close relationship with the mold. The shape of the mold determines the shape of these products, the quality and precision mold processing will determine the quality of these products. Material for various products, appearance, specifications and use of different mold into the casting mold, forging mold, die casting, stamping die and other non-plastic mold and plastic mold.
 The design of  handlebar belongs to a stamping die, in the production of stamping, often several single stamping process in a die to complete, this in a press working stroke, in a die of the same position at the same time completed two or more than two kinds of basic processes of the mold is called compound die.
[Key words]  handlebar     Stamping die.

目录
中文摘要 ……………………………………………………………………….…..VI
外文摘要 …………………………………………………………………….….....VII
1前言 1
1.1冲压加工的特点及其应用 1
1.2冲压模具的现状及发展方向 2
1.3当前存在的问题 4
2方案论证 5
2.1零件加工工艺分析 5
2.2冲裁过程 5
2.3断面特征 7
2.4冲裁力的计算 7
2.5卸料力的计算 9
2.6冲压设备的选择 11
2.7冲裁间隙的确定 11
2.8凸、凹模刃口尺寸的计算 12
2.9 模具结构 15
2.10冲压模具材料选择 17
3冲压模具的安装、调试和日常修理与保养 18
3.1 模具安装的一般顺序： 18
3.2 冲模的试冲和调整 19
4总结 19
参考文献 21
致   谢 22
